Dual-Channel UHF Wireless Microphone System

Overview

This advanced dual-channel UHF wireless microphone system is designed for professionals seeking high-quality audio transmission. With the capability to support two transmitters simultaneously, it ensures seamless communication and performance in various settings, from live events to studio recordings.

Key Features

• Dual-Channel Technology: Operates with two transmitters at once, enhancing versatility.
• Advanced DSP Processing: Utilizes a secondary DSP receiver for superior resistance against interference.
• Professional Circuit Design: Incorporates a LOW-CUT function to eliminate unwanted low-frequency noise.
• Flexible Audio Output Options: Offers both mono and stereo output configurations.
• Real-Time Monitoring: Includes a headphone interface for immediate audio feedback during use.
• Independent Volume Control: Allows separate adjustments for monitoring and audio output with memory retention capabilities.
• Noise Reduction Technology: Employs WNCRS technology to minimize environmental and wind noise effectively.
• Dynamic Audio Response: Features a high-performance audio expander that enhances real-time dynamic range.
• Extensive Channel Availability: Provides 100 wireless channels, enabling multiple groups of channels to operate concurrently without interference.
• Versatile Input Support: Compatible with both line-in (linear input) and MIC-in (microphone input).
• Camera Charging Capability: Supports charging via camera connections with a current of 600mA.

Specifications

1. Frequency Response Range: 30Hz – 18KHz
2. Sound Transmission Delay Time: <0.15 ms
3. Microphone Type: Capacitive omnidirectional
4. De-emphasis Time Constant: 50uS
5. Signal-to-noise Ratio (S/N): >90 dB
6. Maximum Frequency Deviation Tolerance: +/-50 kHz
7. Mute Level Sensitivity Thresholds at 15 dBuV
8. Total Harmonic Distortion Rate (THD): >0.9%
9. Number of Available Channels Supported by Device : 100
10. Indicator Lights Present for RF & IR Status

11.Audio Output Level Specification : >48 dBV
12.Reference Operating Distance in Open Areas : Up to 60 meters
13.Audio Output Interface Type : Standard 3.5 mm jack
14.Antenna Type Used : Adjustable angle spring antenna (1/4 wavelength)
15.Headphone Output Power Rating : Level at approximately 15mW (16 ohm)
16.Power Supply Options Include : DC voltage options of either 2 AA rechargeable batteries or external USB mobile power supply rated at current capacity of up to600mA
17.Battery Life Expectation Based on Usage Scenarios

Packing List

1. Receiver x1

2.Transmitter x2
3.User Manual x1
4.Audio Cable Male-to-Male Elbow Connector x1
5.Microphones Male Connector x2
6.Canon Male Connector Adapter Cable x1
7.Boot Holder Type Stand x1

This product is ideal for musicians, presenters, or anyone needing reliable wireless sound transmission without compromising quality.
